PNP517C

CUSTOMIZABLE POP ‘N PLUG TOWER FOR CUSTOM SURFACE COVER

  • Customizable to almost any table top
  • Dual-sided connectivity
  • Smooth new look on all sides
  • Cutout always matches table surface
  • Simple, slide-in installation
  • Opens/closes by pressing on top
  • Gas spring lift mechanism
  • 8-10 day lead time (5 pieces or less)
  • NOT UL LISTED
  • NOT AVAILABLE FOR SALE IN CANADA
  • As seen in the Altinex Table Top Interconnect Guide
  • Downloadable cutout template available
  • The price of the unit includes all connectors
  • Ten year warranty
SKU: PNP517C Category:

  PNP517C Overview

The PNP517C is a customizable dual-sided tower interconnect box that uses a custom cut-out tabletop surface for a perfect match with the table surface.

  Summary

The innovative, powerful PNP517C tower with custom tabletop surface is designed to work with most tabletops with a thickness of up to 1.125 inch (29 mm). The unit’s cover is your own rectangular table cutout, that gives an elegant and perfect match to your own table while offering unequaled AV connectivity. The PNP517C will lift cutouts weighing up to 22 oz (0.624 kg)!

As a customizable dual-sided unit, the PNP517C is designed with a total of two (2) plates and with the following connectors and ports on each plate: four (4) AC power, two (2) D-Sub, two (2) 3.5 mm audio, and and five (5) snap-ins. Various connector options are offered to ensure your A/V requirements are met. All connectors are female, and all cables come in 6-foot lengths

ALTINEX products are protected by the following patents: D534495, D475016, D580357, D446188, D442143

  Technical Specifications

GENERAL

ELECTRICAL

AC Power: NEMA 5-15 (8)Power Rating (pass-through power): 120 VAC, 60 Hz, 5A
Video: 15-pin HD (4)
Audio: 3.5mm (4)
Network: RJ-45 (4)
Modem: RJ-11 (4)
Composite Video: RCA (2)

MECHANICAL

ACCESSORIES

AC Power Cord: 10ft (3m)Included: Mounting screws, cable clamps
Audio, Video, and Commnication: 6ft (2m)Top not included
Min. Table Thickness: 0.75in (19mm)Replacement Gas Spring: AC401-305
Max. Table Thickness: 1.125in (29mm)
Max. weight of custom top: 22oz (0.624kg)
Width: 5.65in (144mm)
Depth: 5.45in (138mm)
Height, opened: 5.10in (130mm)
Height (below tabletop): 8.75in (222mm)
Width (below tabletop): 8.50in (216mm)
Depth (below tabletop): 6.125in (156mm)
Finish: Matte Black
T° Operating: 10°C-35°C
T° Maximum: 40°C
Humidity: 90% non-condensing

WARRANTY

TOP COVER DIMENSIONS (MAX. SIZE)

3 year warrantyFront Width: 5.665in (143.51mm)
1 year warranty on gas-springSide Width: 5.45in (138.43mm)
Corner Radius: 0.30in (7.62mm)

  Related Products

PNP ACCESSORIES – FOR A COMPLETE LIST OF SECTIONAL PLATES FOR PNP517C

CONNECTOR OPTIONS

Snap-In Connector Assemblies
